Instrument Introduction:

The fruit and vegetable respiration tester is specifically designed for measuring and analyzing the respiratory intensity of fruits and vegetables under storage conditions such as room temperature, refrigerated storage, controlled atmosphere storage, and supermarket refrigerators. The feature of this instrument is that it can adapt to the characteristics of fruits and vegetables

Choosing different volumes of breathing chambers based on their size accelerates the balance and measurement time; It can display the CO2 concentration, O2 concentration, temperature, and humidity of the breathing room simultaneously. This instrument has the characteristics of multifunctionality, high precision, speed, efficiency, and convenience, and is very suitable for respiratory measurement of various fruits and vegetables in schools and research institutes such as food, horticulture, fruits, vegetables, and foreign trade.

Instrument features

1. Chinese LCD screen with 160 × 320 dot matrix, easy to operate and clear interface

2. Using a large capacity SD card to store data, with a large storage capacity and easy export

3. Equipped with a power on calibration function, the instrument can be calibrated or not when turned on to improve its accuracy

4. Equipped with dedicated respiratory intensity calculation software, users can quickly calculate the results

5. Adjustable gas flow rate

Technical indicators:

Carbon dioxide detection

1. Detection principle: infrared

2. Minimum measurement range: 0-5000ppm

3. Linearity: ≤± 1% F.S

4. Repeatability: ≤± 1%

5. Response time: ≤ 15s

6. Zero drift: ≤± 2% F.S/24h

7. Terminal drift: ≤± 2% F.S/24h

Oxygen detection

1. Detection principle: electrochemical method

2. Measurement range: 0-30%

3. Linearity: ≤± 2% F.S

4. Repeatability: ≤± 1%

5. Response time: 30s

6. Zero drift: ≤± 2% F.S/24h

7. Terminal drift: ≤± 2% F.S/24h

Temperature detection

Measurement range: -20-95 ℃ Resolution: 0.1 ℃ Accuracy: ± 0.2 ℃

Humidity detection

Measurement range: 0-100% Resolution: 0.1% Accuracy: ± 0.2% F.S

Power supply: AC220V ± 10%

Preheating time: 30 minutes

Comes standard with three breathing chamber sizes:

1. A net space of 80mm with an inner diameter of 40mm and a volume of 0.1 liters

2. A net space of 89mm with an inner diameter of 60mm and a volume of 0.25 liters

3. A net space of 180mm with an inner diameter of 120mm and a volume of 2 liters

Users of other sizes of breathing chambers can order separately according to their own needs

[Basic Product Configuration]

Accessory name and quantity

One host

Three sets of breathing rooms

One power cord

One card reader

One storage card

Two trachea

One software CD

One instrument box

General testing process:

1. Place the fruit or vegetable to be tested into the corresponding breathing chamber and tighten the lid of the breathing chamber

2. Connect the host to the breathing chamber using a trachea, connect the host power supply, and power on the host

3. Set the collection time interval and enter the username to enter data measurement, then turn on the air pump for preheating

After preheating for about 30 minutes, press the "confirm" button to start automatically recording data changes

5. After the test is completed, disconnect the host power, remove the SD card, and import the data into the computer

6. Input the recorded data into the respiratory intensity calculation software, calculate and save the results
