Product Introduction:

The comprehensive pesticide residue detector not only follows the national standard for the detection of organic phosphorus and amino ester pesticides, but also can accurately detect specific pesticides, including imidacloprid, thiacloprid, carbendazim, carbendazim, chlorpyrifos, ipratropium, imidacloprid, fipronil, azithromycin, methomyl, triazophos, paraquat, methomyl, imidacloprid, imidacloprid 2-in-1, imidacloprid carbendazim 2-in-1, methyl parathion, acetamide, avermectin, organophosphate, metocloprid, imidacloprid, thiacloprid, triazolone, chlorpyramide, and multi effect pesticides. azole, chlorothiacloprid, fipronil, thiamethoxam, phoxim, cypermethrin, benzofenapyr, 4-chlorophenoxyacetic acid, 2,4-dichlorophenoxyacetic acid, 2,4,5-trichlorophenoxyacetic acid, 6-benzyladenine, herbicide, imidacloprid, isofungicide Flupheniram, prochloraz, cypermethrin, efficient cyhalothrin, dimethoate, fluazuron, imidacloprid, thiamethoxam, enoxymorpholine, pyrimethanil, fluazuron, pyrimethanil, triazolone/triazolone, fipronil, tebuconazole, cypermethrin, chlorfenapyr, diazinon, oxytetracycline, methylpyridine phosphate, amitriptyline, and many other insecticide compounds.

Detection method: Enzyme inhibition rate colorimetric method is used for the detection of organophosphorus and carbamate pesticides, in accordance with the national standard method (GB/T5009.199-2003). Acetylcholinesterase and butyrylcholinesterase reagents can both be used, meeting the requirements of national standards and the standards of the Ministry of Agriculture; The sub item detection is based on colloidal gold immunochromatography for rapid and accurate detection of numerous insecticides.

Widely used for rapid detection of organophosphate and carbamate pesticide residues in foods such as vegetables, fruits, tea, grains, and agricultural products; In addition, it can also be used for on-site testing in fruit and vegetable tea production bases and agricultural wholesale sales markets, as well as safety speed testing before fruit and vegetable processing in restaurants, schools, canteens, and households.

Functional features: Functional features:

1. ★ Android intelligent operating system, adopting a more efficient UI interactive interface, the instrument has WiFi network upload, 4G network transmission, GPRS wireless remote transmission, network cable connection functions, and can quickly upload data in batches.

2. High degree of intelligence, the instrument has self checking function: it has power on self checking and zero adjustment functions, and automatic detection of repeatability function.

3. The new generation of high-speed thermal printers can automatically print or batch print inspection reports and QR codes upon completion of testing.

4. ★ The instrument is equipped with a supervision platform, and the data can be uploaded on the LAN and Internet, and the test results can be directly transmitted to the food safety supervision platform. Conduct regional food safety supervision, big data analysis and processing, and data statistics, detect the long-term and short-term dynamics of regional food safety, and achieve food safety problem estimation and early warning

5. Integrated host, including food safety detection module, multi-channel pesticide residue detection module, and colloidal gold immunochromatographic detection module.

6. Integrated portable rapid testing equipment, meeting the needs of on-site and mobile testing, capable of detecting all testing items under the same software, and displaying testing results intuitively through the same window.

7. ★ The colorimetric cell can be equipped with temperature control function, which can increase or decrease the temperature, optimize the pre-treatment process, and effectively compensate for environmental influences to ensure the detection results

8. ★ Double colloidal gold module detection method: track type automatic transmission scanning, automatically exits the detection card after the detection is completed.

9. The instrument is equipped with a built-in camera for taking photos, which can display real-time images of the gold label card. The system automatically analyzes and presents CT coordinate curves, and CT lines are automatically recognized without manual adjustment.

10. Built in powerful database with multi category and multi type sample menu function, allowing flexible selection of testing samples. Different testing channels can simultaneously test different sample items. It is also possible to directly edit and input information such as sample name, detection indicators, and sending unit on the instrument, and save them into the sample database.

11. ★ The instrument is equipped with built-in operation videos, which can be quickly learned by clicking on the video module. It is your laboratory guidance expert by your side.

12. Sample processing is simple and labor-saving, and the overall operation is fast, safe, and convenient.

13. ★ The instrument can be configured with identity recognition function, which can be turned on through password or ID flashing to prevent non staff operations.

14. High sensitivity, high detection accuracy, high repeatability accuracy, scanning high-precision optical sensor.

15. The instrument has the functions of recalibration, locking, and factory reset.

16. The result judgment line can be modified, the reference value calibration value can be saved, and data will not be lost when power is turned off.

17. Compatible with all colloidal gold cards on the market, with unrestricted use of consumables, greatly enhancing the user experience. 16. The instrument has the functions of recalibration, locking, and factory reset.

Main parameters:

1. The main control chip adopts ARM Cortex-A7, RK3288/4-core processor, with a main frequency of 1.88GHz, faster operation speed and stronger stability.

2. 12 detection channels, capable of batch and rapid detection of multiple samples,

3. Display mode: 7-inch LCD touch screen display, user-friendly Chinese operation interface, intuitive and simple reading.

4. Dual use AC/DC, equipped with a 6-hour large capacity rechargeable lithium battery, convenient for outdoor mobile testing, DC 12V power supply, can be connected to car power supply.

5. Intelligent constant current and voltage stabilization, automatic adjustment and calibration of light intensity, and long-term continuous operation of the light source without temperature drift phenomenon.

6. Sample numbers are automatically accumulated.

7. The data can be uploaded wirelessly to the platform and exported as an Excel spreadsheet.

8. Storage capacity for 200000 test results

9. Simultaneously supports USB copying, standard USB interface, and driver free plugging and unplugging.

10. The detection items are expandable and the firmware can be upgraded

11. Instrument size: 43 × 35 × 19cm, net weight of host: 5.2kg

Technical parameters;

*Wavelength configuration: 410nm;

*Inhibition rate display range: 0% to 100%;

*Inhibition rate measurement range: 0% to 100%;

*Transmittance accuracy: ± 1.5%;

*Transmission density repeatability: ≤ 0.5%;

*Drift: ≤ 0.005Abs/3min;

*Inhibition rate indication error: ≤ 10%

*Inhibition rate repeatability: ≤ 5%

Optional features

1) Voice enrollment function can be added, providing humanized guidance for operation.

3) The instrument can achieve self heating function.

4) Large capacity lithium batteries can be configured.
