Instrument usage:

The heavy metal detector can be widely used for rapid detection of heavy metals such as lead, cadmium, hexavalent chromium, mercury, arsenic, iron, nickel, and aluminum in rice, grains, fruits, vegetables, medicinal materials, water quality, and aquatic products. The detection items can be customized according to customer needs.

Functional features:

1. This instrument uses optoelectronic technology to analyze and test the reflectivity of reaction products, quantitatively or qualitatively analyzing the content of the analyte in the sample.

2. Android intelligent operating system, 7-inch high-sensitivity true color touch screen, more efficient and user-friendly operation,

3. The instrument has 4G wireless networking, WiFi networking upload, and GPRS wireless remote transmission functions to quickly upload data.

4. Portable instrument, easy to carry and operate on site, with a main unit weight not exceeding 3kg.

5. Equipped with a visible light source, capable of detecting visible light signals with detection values ranging from 0 to 30000.

6. Equipped with commonly used printer data cable interfaces for direct printing of results; Equipped with USB interface, it can connect to the network.

7. It has multiple food safety testing projects, an open platform, and can add or remove testing projects.

8. Detection channels: 12 detection channels, capable of testing multiple samples simultaneously. Each sample is controlled by a program to work independently without interfering with each other.

9. When the standard sample simulating reflectance is around 50%, the precision CV value is ≤ 0.8%.

10. Power supply: (220 ± 22V)~50Hz ± 1Hz, the voltage fluctuation of the power supply should not exceed 220V AC ± 10%.

11. Built in printer, real-time printing of detection results. Built in large capacity battery, convenient for on-site law enforcement inspections.

12. The body stores tens of thousands of test results and can also be exported and stored.

13. Open port, can connect to the regulatory platform database, and the interface has upload operations.

Technical parameters:

◆ Repeatability: ± 0.1% (A)

◆ Repetitive inhibition rate: ≤ 10%

◆ Accuracy of absorbance: ± 2.0%

Stability: ≤ 0.003A/3min

Linear error: ± 1.0%

Size: 360X300X125 (mm)
